- Working Weight1300kg
- EngineKubota/Perkins
- Output Power24.4HP/24.6HP
Powerful, high performance, innovative design to help you work in a variety of applications
Color and logo can be customized. Customize your exclusive work partner according to your ideas
Recommend suitable engines for you according to the environmental protection requirements of your location
We have professional engineers 24 hours a day to answer your questions one-on-one, and you can enjoy a 365-day warranty when placing an order
We have established warehouses in the United States and Europe, where agents and customers can test the machines on site and pick up the goods easily
We can provide you with exclusive customization services, and will produce the products you want according to your requirements, including but not limited to brand customization, color customization and engine customization.
FUNCTION |
|
Rated Load |
450KG |
Bucket Capacity |
0.2m3 |
Maximum Lifting Force |
1200KG |
Working Speed |
0-6.5km/h |
Rated Pressure |
21Mpa |
Lifting Time |
4.3s |
Descending Time |
3.3s |
Tipping Time |
1.5s |
Climbing Ability |
30% |
Working Weight |
1300KG |
ENGINE |
|
Brand |
Kubota / Perkins |
Model |
D1105/403J-11 |
Output Power |
18.2KW/3000rpm ; 18.4KW/2800rpm |
Maximum Torque |
70.4Nm/2200rpm ; 66.9Nm/2100rpm |
Engine Oil |
5.1L/4L |
CAPACITY |
|
Fuel Tank |
35 L |
Hydraulic Oil Tank |
25L |
HYDRAULIC SYSTEM |
|
Hydraulic Pump |
ltaly PWG/Bondioi&Pavesi |
Hydraulic Motor |
Denmark Danfoss |
Valve |
ltaly Hydrocontrol |
Auxiliary System Pressure |
180 bar |
Auxiliary System Flow |
36 L/min |
