- Bucket capacity1.3m³
- Power85kW
- Weight8000kg
- Dimension7800*2100*3200mm





Powerful, high performance, innovative design to help you work in a variety of applications
Customize your exclusive work partner according to your ideas
Recommend suitable engines for you according to the environmental protection requirements of your location
We have professional engineers 24 hours a day to answer your questions one-on-one, and you can enjoy a 365-day warranty when placing an order
We have established warehouses in the United States and Europe, where agents and customers can test the machines on site and pick up the goods easily
Ensure your products are delivered safely to your doorstep.

The two-end loader is equipped with working devices at both ends, which can load and unload at both ends at the same time, reducing the number of round trips and greatly improving work efficiency. For example, at the construction site, it can load materials while unloading them to the designated location, saving a lot of time.
| Overall dimensions | 7800*2100*3200mm |
| Wheelbase | 2480mm |
| Minimum ground clearance | 350mm |
| System pressure | 12MPa |
| Machine weight | 8000kg |
| Maximum speed | 30km/h |
| Steering angle | 36° |
| Engine model | Yuchai 4105Turbo |
| Engine type | In line direct injection Four-Stroke and water-cooling |
| Rated power | 85kW |
| Bucket capacity | 1.3m³ |
| Breakout force | 38KN |
| Loading lifting capacity | 2800kg |
| Bucket dumping height | 3600mm |
| Bucket dumping distance | 1062mm |
| Backhoe capacity | 0.3m³ |
| Max.digging depth | 4100mm |
| Max.pulling force | 39KN |
